Thinking about converting your BRX01 AWB between link and leaf suspension? This article walks you through the process step by step.

To convert your BRX01 AWB between link and leaf suspension, here are a

Conversion from full leaf to full link suspension:

Stainless Steel Links - BRLC70228 / BRLC70229 / BRLC70230 / BRLC70231 / BRLC70232 / BRLC70233
Front Coilover 80mm Shocks - BRSH0080-SP (x2)
Rear Coilover 70mm Shocks - BRSH0070-SP (x2)
High-Clearance Center Alum Skid Plate Link Mount - BRX020020 (+M3x12 RS x4)
Panhard Mounts - BRX020024 / BRLC7074A
Panhard hardware - M3x18 CSS (x4) / M3x8 RS (x2)
Spacers - BRLC7040 (x2) + BRLC7042 (x2)
Side Bracket replacement hardware - M2.5x6 RS (x2)
Links hardware - BRASST4016 (x8) / BRASST4004 (x4) / BRASS471 (x3)
Rod End / Pivot ball - BRW750306A (x11) / BRW750307D (x5) / BRW750310 (x16)
Additional hardware - M3x12 RS x2 / M3x14 RS x2 / M3 x 16 RS x6 / M3x18 RS x5 / M3x20 RS x2 / M3x26 RS x2 / Nut M3 x 3
